Elastomer Diaphragms are sealing elements that act as flexible movable partitions providing hermetic sealing against two chambers. At the same time, they can perform a stroke movement that is perpendicular to the clamping plane. Diaphragms require no maintenance, no lubrication, they operate wear-free and have a long life performance. Thin-walled designed types run almost frictionless without breakaway torques.
In our production, Diaphragms are constructed with single components and can be varied (according to customer specifications). For example with or without fabric reinforcement, foil lamination and metal core. We offer all established material combinations, if neeeded also with KTW, FDA and W270 compliance. Our technical consultants will gladly assist you in your product development.
Diaphragms
Fields of application
static
dynamic
single acting
double acting
Linear
Rotating
oszilating
Main use
pump industry, process measurement and control technology, pneumatic actuators
Materials
elastomers, fabric reinforcement, metal, PTFE
Technical values
Materials
elastomer, fabric, metal
Pressure
up to 0,07 MPa
Temperature
-50°C / +120°C (material dependent)
Speed
application dependent
Maximum values temperature, speed and pressure are simultaneously not applicable! The values vary in dependence of material and media. For technical queries please contact our application consultants – we have the right solution for you.
